Capacitor
Aluminum Electrolytic Capacitors (Radial Lead Type)
EEUHD1H4R7B
Weight:
0
g
Panasonic HD-A Series EEUHD1H4R7B
Model
:
EEUHD1H4R7B
Catalogue
HD-A Series Catalogue English (Download)
HD-A Series Catalogue Chinese (Download)
HD-A Series Catalogue Japanese (Download)
3D Data
3D EEUHD1H4R7B (Download)
Add to Basket
In your cart
Add to Basket
Contact us about this product
Description
Description
Manufacturer
Panasonic
Model
EEUHD1H4R7B
General
Appearance
P.E.T. sleeve sheathing (metal case)
Series
HD-A
Mounting
Mounting Method
Radial lead type
Dimensions
Lead (terminal) Pitch
5.0mm
Diameter
5.00mm
Length
11.00mm
Electrical
Capacitance
4.70µf
Rated Ripple Current-1
26mA
Rated ripple current-1 (unit)
ｍArms
Rated ripple current-1 freq.
120Hz
Capacitance Tolerance
±20%
Polarity type
Polar
Dissipation Factor (DF) Max.
0.12
Rated voltage
50.0V
Leakage current .Max
3µA
Environmental
Category temperature range
－55℃ ～ ＋105°C
Packaging
Min. Packaging (Pcs)
1000
