EEEHD1C472AM
Panasonic HD [Medium-size] (High temp. reflow) Series EEEHD1C472AM
Model
:
EEEHD1C472AM
Catalog
Catalogue
HD [Medium-size] (High temp. reflow) Series Catalogue English (Download)
HD [Medium-size] (High temp. reflow) Series Catalogue Chinese (Download)
HD [Medium-size] (High temp. reflow) Series Catalogue Japanese (Download)
Specification
3D
Add to Basket
In your cart
Add to Basket
Contact us about this product
Description
Description
Manufacturer
Panasonic
Model
EEEHD1C472AM
Mounting
Mounting Method
Surface Mount
Dimensions
Diameter
18.00mm
Length
16.50mm
Electrical
Capacitance
4700µf
Leakage current .Max
752µA
Rated ripple current freq.
120Hz
Rated ripple current
1540.0mA
Rated voltage
16.0V
Polarity type
Polar
Environmental
Category temperature range
－40 ～ ＋105°C
Packaging
Packing Specification
Embossed carrier taping (reel packing)
