BMOV14D142K
Bencent MOV BMOV14D142K
Model
:
BMOV14D142K
Catalogue
BMOV14D142K Catalogue English (Download)
Add to Basket
In your cart
Add to Basket
Contact us about this product
Description
Description
Manufacturer
Bencent
Model
BMOV14D142K
Overvoltage Protection Components
Metal Oxide Varistors (MOV)
Type
Normal Energy
Maximum Allowable Voltage VAC
880V
Maximum Allowable Voltage VDC
1140V
Varistor Voltage 1mA
1400(1260~1540)V
Maximum Clamping Voltage IP
50A
Maximum Clamping Voltage VC
2310V
Withstanding Surge Current
4500A
Maximum Energy 10/1000μs
238J
Rated Power
0.6W
Typical Capacitance (Reference) @1KHz
150pF
Operating Temperature
－40℃~～＋105℃
Body Length (L)
16.5mm
Body Width (W)
14mm
Body Height (H)
10.5mm
Min. Packaging (Pcs)
150
250
300
400
500
750
