Capacitor
Solid Capacitor
25SEK82M+3
Weight:
0.35
g
Panasonic SEK Series 25SEK82M+3
Model
:
25SEK82M+3
Catalogue
SEK Series Catalogue English (Download)
SEK Series Catalogue Chinese (Download)
SEK Series Catalogue Japanese (Download)
3D Data
3D 25SEK82M+3 (Download)
Add to Basket
In your cart
Add to Basket
Contact us about this product
Description
Description
Manufacturer
Panasonic
Model
25SEK82M+3
General
Series
SEK
Mounting
Mounting Method
Radial lead type
Dimensions
Lead (terminal) Pitch
2.5mm
Size Code
C6
Diameter
6.30mm
Length
6.00mm
Electrical
Capacitance
82.00µf
Endurance@Temp.-1
1000@125°C
Rated Ripple Current-1
3060mArms
Rated ripple current-1 freq.
100kHz
Rated Ripple Current-1 Temp.
T≦105°C
Rated Ripple Current-2
960mArms
Rated ripple current-2 freq.
100kHz
Rated Ripple Current-2 Temp.
105°C
Endurance
1000h
Capacitance Tolerance
±20%
Polarity type
Polar
Dissipation Factor (DF) Max.
0.12
Rated voltage
25.0V
Equivalent Series Resistance (E.S.R.)
25mΩ
Equivalent Series Resistance (E.S.R.) freq.
100kHz
Leakage current .Max
410µA
Mechanical
Number of Terminals
2
Environmental
Category temperature range
－55 ～ ＋125°C
Packaging
Packing Specification
Lead terminal cutting (bulk, bag packing)
Min. Packaging (Pcs)
500
